DiGiCo Orange Box - DANTE2 to KLANG 2 RU Unit with Dual PSUs
DiGiCo Orange Box - DANTE2 to KLANG 2 RU Unit with Dual PSUs
With DiGiCo’s compact 2U Orange Box, you can use DMI (DiGiCo Multichannel Interface) cards to create audio paths over whatever interface you desire. The Orange Box comes with redundant power supplies and two DMI card slots.
It comes with the DMI-KLANG card that provides 16 immersive mixes, each with 64 inputs. It has 2 EtherCON ports and 1 RJ45 port switched together for connecting to console network port and devices running the KLANG:app. It also has a USB port for software updates and preset exchange. The DMI-KLANG works at both 48kHz and 96kHz.
Features:
- Compact 2U Rackmount Chassis
- Redundant Power Supplies as standard
- Convert between formats using DiGiCo DMI cards
Specifications:
- Connections:
- 2 x DMI Slots (up to 64 I/O per slot)
- 1 x USB Remote (USB 2.0 Type B)
- 1 x Word Clock I/O BNC
- 2 x Redundant PSUs
- Signal Processing:
- Bidirectional format conversion
- Up to 64 inputs and 64 outputs
- Options:
- Compatible Cards: ADC / AES / Aviom / DAC / Dante / Dante64@96 / Hydra 2 / KLANG / MADI B / MADI C / ME / Opto / Waves
- Physical:
- Dimensions: 482.6 mm (w) x 262.5mm (d) x 88.1mm (h)
- Weight: 5kg
- Power Requirements: 100-240 VAC, 50-60Hz, 0.8A
- Redundancy: Internal PSU x 2
- Product Code: X-OB
Product Information
Product Information
Shipping & Returns
Shipping & Returns
DiGiCo Orange Box - DANTE2 to KLANG 2 RU Unit with Dual PSUs
DiGiCo Orange Box - DANTE2 to KLANG 2 RU Unit with Dual PSUs
DiGiCo Orange Box - DANTE2 to KLANG 2 RU Unit with Dual PSUs
With DiGiCo’s compact 2U Orange Box, you can use DMI (DiGiCo Multichannel Interface) cards to create audio paths over whatever interface you desire. The Orange Box comes with redundant power supplies and two DMI card slots.
It comes with the DMI-KLANG card that provides 16 immersive mixes, each with 64 inputs. It has 2 EtherCON ports and 1 RJ45 port switched together for connecting to console network port and devices running the KLANG:app. It also has a USB port for software updates and preset exchange. The DMI-KLANG works at both 48kHz and 96kHz.
Features:
- Compact 2U Rackmount Chassis
- Redundant Power Supplies as standard
- Convert between formats using DiGiCo DMI cards
Specifications:
- Connections:
- 2 x DMI Slots (up to 64 I/O per slot)
- 1 x USB Remote (USB 2.0 Type B)
- 1 x Word Clock I/O BNC
- 2 x Redundant PSUs
- Signal Processing:
- Bidirectional format conversion
- Up to 64 inputs and 64 outputs
- Options:
- Compatible Cards: ADC / AES / Aviom / DAC / Dante / Dante64@96 / Hydra 2 / KLANG / MADI B / MADI C / ME / Opto / Waves
- Physical:
- Dimensions: 482.6 mm (w) x 262.5mm (d) x 88.1mm (h)
- Weight: 5kg
- Power Requirements: 100-240 VAC, 50-60Hz, 0.8A
- Redundancy: Internal PSU x 2
- Product Code: X-OB
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
DiGiCo Orange Box - DANTE2 to KLANG 2 RU Unit with Dual PSUs
With DiGiCo’s compact 2U Orange Box, you can use DMI (DiGiCo Multichannel Interface) cards to create audio paths over whatever interface you desire. The Orange Box comes with redundant power supplies and two DMI card slots.
It comes with the DMI-KLANG card that provides 16 immersive mixes, each with 64 inputs. It has 2 EtherCON ports and 1 RJ45 port switched together for connecting to console network port and devices running the KLANG:app. It also has a USB port for software updates and preset exchange. The DMI-KLANG works at both 48kHz and 96kHz.
Features:
- Compact 2U Rackmount Chassis
- Redundant Power Supplies as standard
- Convert between formats using DiGiCo DMI cards
Specifications:
- Connections:
- 2 x DMI Slots (up to 64 I/O per slot)
- 1 x USB Remote (USB 2.0 Type B)
- 1 x Word Clock I/O BNC
- 2 x Redundant PSUs
- Signal Processing:
- Bidirectional format conversion
- Up to 64 inputs and 64 outputs
- Options:
- Compatible Cards: ADC / AES / Aviom / DAC / Dante / Dante64@96 / Hydra 2 / KLANG / MADI B / MADI C / ME / Opto / Waves
- Physical:
- Dimensions: 482.6 mm (w) x 262.5mm (d) x 88.1mm (h)
- Weight: 5kg
- Power Requirements: 100-240 VAC, 50-60Hz, 0.8A
- Redundancy: Internal PSU x 2
- Product Code: X-OB
