Christie Digital 14KHD 14K LM DLP 16:9 Video Projector

Available from Mid-September 2026

Lens not included

With a class leading compact form factor, the Christie HD14K-M projector provides high-performance and feature-rich options that you have come to expect in all Christie products. With embedded warping, blending and color matching, portrait capabilities and a wide variety of high-quality lenses that use our Intelligent Lens System (ILS™), the M series provides extensive installation flexibility for any application. At 14,000 lumens, the Christie HD14K-M also offers high efficiency by giving you more brightness while using less power for a low cost of ownership. Combined with a 3-year warranty and our industry-leading service and support, the M Series offers performance and peace of mind.

Key features

Contrast aperture provides variable contrast ratio from 2500-10000:1 (Full on/off) for crisp, detailed images.
LiteLOC™ - Advanced variable lamp output for color matching across multiple screens
Comprehensive Color Adjustment (CCA™) - Individually adjust each RGB channel for even color matching
Embedded Christie Twist™ image warping and edge-blending
Multi-windowing and screen processing (up to a 2x3 array)
Intelligent Lens System (ILS™) providing motorized zoom, focus, horizontal and vertical offset
Digital keystone correction
Two high definition input channels that allow 4:4:4 HD signals
3D upgradable

Specifications:

ISO lumens: 14062
Center lumens: 13500
ANSI lumens: 12500
Contrast ratio: 10,000:1
Display type: 0.95" 3DLP
Digital micromirror device: 3DLP – 3 x DMD
Resolution: HD (1920 x 1080)
Illumination type: Dual 450W lamp
Illumination performance (hrs): Standard: 1,750 hours, Eco mode: 2,000 hours
Orientation: Portrait OR 360° vertically
Scan rates: Horizontal: 15 to 120 kHz Vertical: 23.97 to 150 Hz
Pixel clock rate: 165MHz
Standard inputs:
- Twin DisplayPort input card
- Dual-link DVI input card
- 3G SD/HD-SDI
Optional inputs:
- Dual-link DVI
- Dual 3G SD/HD-SDI
- Twin HDMI w/Active loop through
- Twin DisplayPort input card
- Dual-link DVI input card
- 3G SD/HD-SDI
Input signals:
- HDTV formats VGA through to QXGA (2048 x 1536)
- Accepts all current HDTV/DTV formats
- Multistandard video decoder
- Horizontal and vertical scaling, all inputs
Control and networking:
- RS232 in/out
- RS422 in
- Ethernet (10/100)
- USB
- GPIO (RS232 9-pin male connector)
- Built-in backlit LCD keypad
- Remote control (with optional wired XLR connection)
Optical system:
- Dust-sealed, 3-chip, DMD light engine
- Scheimpflug (tilt) adjustment
- Built-in light shutter
- Motorized horizontal and vertical lens offset
- Tool-free lens insertion system
Fixed lenses:
- 0.67:1 ILS lens
- 1.1:1 ILS lens
Zoom lenses:
- 1.16-1.49:1 ILS lens
- 1.4-1.8:1 ILS lens
- 1.8-2.6:1 ILS lens
- 2.6-4.1:1 ILS lens
- 4.1-6.9:1 ILS lens
- 6.9-10.4:1 ILS lens
Lens offsets:
- +/- 120% Vertical
- +/- 54% Horizontal
- ALL LENSES EXCEPT BELOW
- 0.67:1 (±35%V / ±12%H)
- 1.16-1.49:1 (±102%V / ±40%H)
Standard accessories:
- IR remote
- Line cord
Enhanced feature sets:
- 99 channel memories
- Black level blending
- Auto setup
- Digital keystone correction
- 3D upgradable
- Dust sealed engine, filter-free design - Although the unit can be run without filters, Christie recommends using filters for assured performance
- Menus in five languages
Operating voltage: 110-240 VAC 50/60 Hz
Operating current: 15A @ 100 VAC
Power requirements:
- 110-240 VAC 50/60 Hz operating voltage
- 15 A @100V operating current
- 1500W power consumption
- 5118 BTU/hr dissipation
Dimensions (LxWxH):
- 22.1"x 19.7"x 10.2"
- 561mm x 500mm x 259mm
Weight: 55lbs (25kg)
Operating environment:
- Temp: 40 to 104° F (5 to 40° C)
- Humidity: 20-80% non-condensing
Regulatory approvals:
- UL/CSA/IEC 60950 (3rd edition)
- FCC Class A, CE, CCC
- This product conforms to all relevant European directives, standards, safety, health and environmental concerns
- RoHS, WEEE
